RT12C2P200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Wirewound Trimmer 20 Ohm 5% 1W 22(Elec)Turn 2.92mm (33.22 X 4.83 X 8mm) Pin Thru-Hole Tube
PDF
/
Inventory: 2462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Chassis Mount
Resistive Material Wirewound
Technical
Packaging Tube
Published 2012
Series Trimpot? RT12 - Sealed
Size / Dimension Rectangular - 0.315 x 0.190 Facex1.250L 8.00mmx4.83mmx31.75mm
Tolerance ±5%
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±50ppm/°C
Resistance 20Ohm
Power (Watts) 1W
HTS Code 8533.31.00.00
Technology WIRE WOUND
Resistor Type TRIMMER
Base Part Number RT12C2
Reference Standard MIL-PRF-27208
Termination Style PC Pins
Rated Power Dissipation (P) 1W
Operating Temperature (Max) 150°C
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 12.7mm
Lead Diameter 0.71 mm
Rated Temperature 70°C
Adjustment Type Side Adjustment
Number of Turns 22
Actuator Orientation HORIZONTAL
Rotation Angle 7920 deg
Ganging Number 1
Compliance
RoHS Status ROHS3 Compliant
