RT12C2P103
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
WIRE WOUND Wirewound MIL-PRF-27208 TRIMMER Trimmer Potentiometer ±5% 7920deg 1W 70C
PDF
/
Inventory: 7002
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Chassis Mount
Weight 2.83g
Resistive Material Wirewound
Technical
Packaging Tube
Published 2007
Series Trimpot? RT12 - Sealed
Size / Dimension Rectangular - 0.315 x 0.190 Facex1.250L 8.00mmx4.83mmx31.75mm
Tolerance ±5%
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
ECCN Code EAR99
Temperature Coefficient ±50ppm/°C
Resistance 10kOhm
Max Operating Temperature 150°C
Min Operating Temperature -55°C
HTS Code 8533.31.00.00
Power Rating 1W
Technology WIRE WOUND
Depth 4.83mm
Resistor Type TRIMMER
Base Part Number RT12C2
Military Standard MIL-PRF-27208
Termination Style PC Pins
Rated Power Dissipation (P) 1W
Actuator Type SCREW
Lead Length 12.7mm
Lead Diameter 0.71 mm
Rated Temperature 70°C
Adjustment Type Side Adjustment
Number of Turns 22
Actuator Orientation HORIZONTAL
Rotation Angle 7920 deg
Ganging Number 1
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
