RJR50FP100P
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Cermet Trimmer 10 Ohm 10% 1/2W 0.1% 1Turn (6.35 X 6.22mm) Pin Thru-Hole Tube
PDF
/
Inventory: 3651
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape WIRE
Resistive Material Cermet
Technical
Packaging Tube
Published 2016
Series Trimpot? RJ50/RJR50-Sealed
Size / Dimension Round - 0.250Dia x 0.228 H 6.35mmx5.79mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 10Ohm
Terminal Finish Tin/Lead (Sn/Pb)
Power (Watts) 0.5W 1/2W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Construction Trimmer Pot
Resistor Type TRIMMER
Reach Compliance Code not_compliant
Base Part Number RJR50
Reference Standard MIL-PRF-39035
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 4.75mm
Lead Diameter 0.46 mm
Rated Temperature 85°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 240 deg
Compliance
RoHS Status Non-RoHS Compliant
