3386V-1-201LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 200 OHM 0.5W PC PIN
PDF
/
Buying Options
Total Price: USD $1.73
Unit Price: USD $1.7336
≥1 USD $1.7336
≥10 USD $1.52064
≥100 USD $1.363296
≥500 USD $1.311024
≥1000 USD $1.258576
≥3000 USD $1.206102
Inventory: 55
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape WIRE
Weight 850.485694mg
Resistive Material Cermet
Technical
Packaging Tube
Published 2005
Series Trimpot? 3386 - Sealed
Size / Dimension Square - 0.375 x 0.375 Face x 0.190 H 9.53mmx9.53mmx4.83mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
Temperature Coefficient ±100ppm/°C
Resistance 200Ohm
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Power (Watts) 0.5W 1/2W
Subcategory POTENTIOMETER
Power Rating 500mW
Voltage - Rated DC 300V
Max Power Dissipation 500mW
Depth 9.53mm
Construction Trimmer Pot
Resistor Type TRIMMER
Base Part Number 3386V
Military Standard Not
Termination Style PC Pins
Voltage - Rated AC 300V
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Lead Length 5.97mm
Lead Diameter 500 μm
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 280 deg
Dimensions
Height 4.826mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
