3386S-1-254
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 250KOHM 0.5W PC PIN SIDE
PDF
/
Inventory: 4413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape WIRE
Weight 850.485694mg
Resistive Material Cermet
Technical
Packaging Tube
Published 2007
Series Trimpot? 3386 - Sealed
Size / Dimension Square - 0.375 x 0.375 Face x 0.375 H 9.53mmx9.53mmx9.53mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
Temperature Coefficient ±100ppm/°C
Resistance 250kOhm
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Power (Watts) 0.5W 1/2W
Voltage - Rated 300V
Subcategory POTENTIOMETER
Power Rating 500mW
Max Power Dissipation 500mW
Construction Trimmer Pot
Resistor Type TRIMMER
Reach Compliance Code not_compliant
Base Part Number 3386S
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Lead Length 5.97mm
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 1
Actuator Orientation HORIZONTAL
Rotation Angle 280 deg
Dimensions
Height 9.525mm
Compliance
RoHS Status Non-RoHS Compliant
