3386H-1-252LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Trimmer Resistors - Through Hole 3/8 2.5Kohms 10% 0.5Watts Square
PDF
/
Inventory: 9431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 4.826mm
Length 9.53mm
Height 9.525mm
Technical
Number of Turns 1
Adjustment Type Side Adjustment
Termination Style PC Pins
Base Part Number 3386H
Depth 4.83mm
Max Power Dissipation 500mW
Power Rating 500mW
Voltage - Rated 300V
Power (Watts) 0.5W 1/2W
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 2.5kOhms
Temperature Coefficient ±100ppm/°C
Termination Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.375 x 0.375 Face x 0.375 H 9.53mmx9.53mmx9.53mm
Series Trimpot? 3386 - Sealed
Published 2007
Packaging Tube
Physical
Resistive Material Cermet
Weight 850.485694mg
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
