3364A-1-202E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Not Linear TRIMMER Trimmer Potentiometer ±25% 260deg 200mW 70C
PDF
/
Inventory: 5030
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2005
Series Trimpot? 3364 - Open Frame
Size / Dimension Rectangular - 0.165 x 0.150 Face x 0.059 H 4.20mmx3.80mmx1.50mm
Tolerance ±25%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 2kOhm
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Composition Cermet, Potentiometer
Power (Watts) 0.2W 1/5W
HTS Code 8533.40.80.50
Power Rating 200mW
Packing Method TR, EMBOSSED, 7 INCH
Max Power Dissipation 200mW
Depth 4.2mm
Resistor Type TRIMMER
Base Part Number 3364A
Military Standard Not
Termination Style J Lead
Rated Power Dissipation (P) 0.2W
Actuator Type SCREW
Rated Temperature 70°C
Adjustment Type Top Adjustment
Number of Turns 1
Taper Linear
Actuator Orientation VERTICAL
Rotation Angle 260 deg
Dimensions
Height 1.4986mm
Compliance
RoHS Status ROHS3 Compliant
