3362H-1-200LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Trimmer Resistors - Through Hole 1/4IN SQ 20 OHMS 10% 0.5WATTS
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.8216
≥1 USD $1.8216
≥10 USD $1.59808
≥100 USD $1.43264
≥500 USD $1.377728
≥1000 USD $1.322552
≥3000 USD $1.267411
Inventory: 263
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Terminal Shape WIRE
Weight 566.990462mg
Resistive Material Cermet
Technical
Packaging Tube
Published 2007
Series Trimpot? 3362 - Sealed
Size / Dimension Rectangular - 0.275 x 0.260 Face x 0.185 H 6.99mmx6.60mmx4.70mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 20Ohm
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Power (Watts) 0.5W 1/2W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Power Rating 500mW
Max Power Dissipation 500mW
Construction Trimmer Pot
Resistor Type TRIMMER
Base Part Number 3362H
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Lead Length 5.46mm
Lead Diameter 0.46 mm
Size Code 2628
Rated Temperature 70°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 240 deg
Dimensions
Height 4.699mm
Compliance
RoHS Status ROHS3 Compliant
