3318F-1-502
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 5K OHM 0.1W PC PIN TOP
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.395564
≥1 USD $0.395564
≥200 USD $0.157837
≥500 USD $0.152559
≥1000 USD $0.149959
Inventory: 4772
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Terminal Shape SNAP-IN
Weight 406mg
Resistive Material Carbon
Technical
Packaging Bulk
Published 2010
Series Trimpot? 3318 - Open Frame
Size / Dimension Square - 0.264 x 0.252 Face x 0.250 H 6.70mmx6.40mmx6.35mm
Tolerance ±30%
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination PC Pin
ECCN Code EAR99
Temperature Coefficient ±1000ppm/°C
Resistance 5kOhm
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Color Natural
Power (Watts) 0.1W 1/10W
HTS Code 8533.40.80.70
Subcategory Variable Resistors
Power Rating 100mW
Max Power Dissipation 100mW
Resistor Type TRIMMER
Reach Compliance Code unknown
Base Part Number 3318F
Termination Style PC Pins
Actuator Type SCREW
Size Code 2526
Rated Temperature 50°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Dimensions
Height 6.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
