3296P-1-253LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 25K OHM 0.5W PC PIN SIDE
PDF
/
Buying Options
Total Price: USD $2.61
Unit Price: USD $2.6136
≥1 USD $2.6136
≥10 USD $2.29416
≥100 USD $2.056736
≥500 USD $1.977536
≥1000 USD $1.898512
≥3000 USD $1.819374
Inventory: 103
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 4.826mm
Technical
Ganging Number 1
Actuator Orientation HORIZONTAL
Taper Linear
Number of Turns 25
Adjustment Type Side Adjustment
Rated Temperature 70°C
Lead Diameter 0.51 mm
Working Voltage 300V
Lead Length 6.4mm
Actuator Type SCREW
Rated Power Dissipation (P) 0.5W
Termination Style PC Pins
Base Part Number 3296P
Resistor Type TRIMMER
Construction Multi-Turn
Depth 11.55mm
Max Power Dissipation 500mW
Voltage - Rated DC 500V
Power Rating 500mW
HTS Code 8533.40.80.50
Power (Watts) 0.5W 1/2W
Color Blue
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
Resistance 25kOhm
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Termination Pin
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension Rectangular - 0.375 x 0.190 Face x 0.190 H 9.53mmx4.83mmx4.83mm
Series Trimpot? 3296 - Sealed
Published 2005
Packaging Tube
Physical
Resistive Material Cermet
Weight 850.485694mg
Terminal Shape WIRE
Mounting Type Through Hole
Mount Panel, Through Hole
Supply Chain
Factory Lead Time 7 Weeks
