3224W-1-201E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Not Linear VERTICAL Trimmer Potentiometer ±10% 4320deg 250mW 85C
PDF
/
Buying Options
Total Price: USD $4.24
Unit Price: USD $4.2416
≥1 USD $4.2416
≥10 USD $3.70832
≥100 USD $3.310912
≥500 USD $3.112208
≥1000 USD $3.045944
Inventory: 1180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 5.08mm
Technical
Rotation Angle 4320 deg
Actuator Orientation VERTICAL
Taper Linear
Number of Turns 12
Adjustment Type Top Adjustment
Rated Temperature 85°C
Size Code 1914
Rated Power Dissipation (P) 0.25W
Termination Style J Lead
Military Standard Not
Base Part Number 3224W
Construction Trimmer Pot
Depth 3.9mm
Max Power Dissipation 250mW
Packing Method TR, EMBOSSED, 7 INCH
Voltage - Rated DC 300V
Power Rating 250mW
Voltage - Rated 300V
Power (Watts) 0.25W 1/4W
Color Natural
Composition Cermet, Potentiometer
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Resistance 200Ohm
Type Potentiometer
Temperature Coefficient ±100ppm/°C
Termination J-Hook
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension Rectangular - 0.189 x 0.138 Face x 0.209 H 4.80mmx3.50mmx5.30mm
Series Trimpot? 3224 - Sealed
Published 2007
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Weight 283mg
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
