3214W-1-103E
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER, SMD, 5 TURN 10K
PDF
/
Buying Options
Total Price: USD $2.7
Unit Price: USD $2.7016
≥1 USD $2.7016
≥10 USD $2.3716
≥100 USD $2.12608
≥500 USD $2.04424
≥1000 USD $1.962488
Inventory: 1228
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Terminal Shape J BEND
Weight 283.495231mg
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 1999
Series Trimpot? 3214 - Sealed
Size / Dimension Rectangular - 0.189 x 0.138 Face x 0.209 H 4.80mmx3.50mmx5.30mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination J-Hook
Temperature Coefficient ±100ppm/°C
Resistance 10kOhm
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Color Natural
Power (Watts) 0.25W 1/4W
Voltage - Rated 300V
Subcategory Variable Resistors
Power Rating 250mW
Voltage - Rated DC 300V
Packing Method TR, EMBOSSED, 7 INCH
Max Power Dissipation 250mW
Depth 3.9mm
Construction Trimmer Pot
Resistor Type TRIMMER
Base Part Number 3214W
Military Standard Not
Termination Style J Lead
Actuator Type SCREW
Size Code 1420
Adjustment Type Top Adjustment
Number of Turns 5
Taper Linear
Actuator Orientation VERTICAL
Rotation Angle 1800 deg
Dimensions
Height 5.55mm
Thickness 5.59mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
