2N6028RLRP
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Programmable Unijunction
Description
THYRISTOR PROG UNIJUNCT 40V TO92
PDF
/
Inventory: 2386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage - Offset (Vt) 600mV
Current - Gate to Anode Leakage (Igao) 10nA
Current - Valley (Iv) 25μA
Current - Peak 150nA
On-State Current-Max 150A
Trigger Device Type PROGRAMMABLE UJT
Voltage - Output 11V
Power Dissipation-Max 300mW
Voltage 40V
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Form THROUGH-HOLE
Terminal Position BOTTOM
Subcategory Programmable Unijunction Transistors
Min Operating Temperature -50°C
Max Operating Temperature 100°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2004
Packaging Tape & Box (TB)
Physical
Number of Pins 3
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
