2N6028G
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Programmable Unijunction
Description
THYRISTOR PROG UNIJUNCT 40V TO92
PDF
/
Buying Options
Total Price: USD $4.42
Unit Price: USD $4.42415
≥1 USD $4.42415
≥10 USD $3.62995
≥100 USD $3.5169
≥500 USD $3.40385
≥1000 USD $3.28985
Inventory: 1367
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 3 days ago)
Physical
Contact Plating Copper, Silver, Tin
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Number of Pins 3
Technical
Published 2006
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -50°C
Subcategory Programmable Unijunction Transistors
Voltage - Rated DC 40V
Terminal Position BOTTOM
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) 260
Current Rating 150mA
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 3
Number of Elements 1
Configuration SINGLE
Power Dissipation 300mW
Voltage - Output 11V
Max Repetitive Reverse Voltage (Vrrm) 40V
Trigger Device Type PROGRAMMABLE UJT
On-State Current-Max 150A
Current - Peak 150nA
Current - Valley (Iv) 25μA
Current - Gate to Anode Leakage (Igao) 10nA
Voltage - Offset (Vt) 600mV
Dimensions
Height 5.33mm
Length 5.2mm
Width 4.19mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
