2N4949
RoHS
/
Package TO-206AA, TO-18-3 Metal Can
Category Discrete Semiconductor Products / Transistors - Programmable Unijunction
Description
THROUGH-HOLE UJT
PDF
/
Inventory: 937
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Peak Point Current-Max 1mA
Emitter Current-Max 50mA
Valley Point Current-Min 2mA
Static Inter-base Res-Min 4 kΩ
Static Inter-base Res-Max 12 kΩ
Intrinsic Stand-off Ratio-Min 0.74
Intrinsic Stand-off Ratio-Max 0.86
Inter-base Voltage-Max 25V
Current - Valley (Iv) 2mA
Current - Peak 1μA
Power Dissipation-Max (Abs) 0.36W
Voltage - Output 3V
Configuration SINGLE
Number of Elements 1
Operating Temperature (Min) -65°C
Operating Temperature (Max) 200°C
JESD-30 Code O-MBCY-W3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Terminal Position BOTTOM
Subcategory Unijunction Transistors
Terminal Finish TIN/LEAD (SN/PB)
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2000
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-206AA, TO-18-3 Metal Can
