2N4948
RoHS
/
Package TO-206AA, TO-18-3 Metal Can
Category Discrete Semiconductor Products / Transistors - Programmable Unijunction
Description
THROUGH-HOLE UJT
PDF
/
Inventory: 3014
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case TO-206AA, TO-18-3 Metal Can
Surface Mount NO
Transistor Element Material SILICON
Technical
Published 2000
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Unijunction Transistors
Terminal Position BOTTOM
Terminal Form WIRE
Reach Compliance Code not_compliant
JESD-30 Code O-MBCY-W3
Operating Temperature (Max) 200°C
Operating Temperature (Min) -65°C
Number of Elements 1
Configuration SINGLE
Voltage - Output 6V
Power Dissipation-Max (Abs) 0.36W
Current - Peak 2μA
Current - Valley (Iv) 2mA
Inter-base Voltage-Max 25V
Intrinsic Stand-off Ratio-Max 0.82
Intrinsic Stand-off Ratio-Min 0.55
Static Inter-base Res-Max 12 kΩ
Static Inter-base Res-Min 4 kΩ
Valley Point Current-Min 2mA
Emitter Current-Max 50mA
Peak Point Current-Max 2mA
Compliance
RoHS Status Non-RoHS Compliant
