PN4093
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Bulk Through Hole N-Channel SINGLE JFET Transistor 8mA @ 20V 8mA 625mW 40V
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2816
≥1 USD $0.2816
Inventory: 6223
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Resistance - RDS(On) 80Ohm
Voltage - Breakdown (V(BR)GSS) 40V
Voltage - Cutoff (VGS off) @ Id 1V @ 1nA
Current - Drain (Idss) @ Vds (Vgs=0) 8mA @ 20V
Feedback Cap-Max (Crss) 5 pF
Drain to Source Resistance 80Ohm
FET Technology JUNCTION
Input Capacitance (Ciss) (Max) @ Vds 16pF @ 20V
Transistor Application SWITCHING
FET Type N-Channel
Power Dissipation 625mW
Operating Mode DEPLETION MODE
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code O-PBCY-T3
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Current Rating 8mA
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position BOTTOM
Voltage - Rated DC 40V
Terminal Finish MATTE TIN
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2000
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
