BFR30LT1G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Tape & Reel (TR) Surface Mount N-Channel SINGLE JFET Transistor 4mA @ 10V 225mW 25V 1.5pF
PDF
/
Inventory: 8318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 3
JESD-30 Code R-PDSO-G3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Operating Mode DEPLETION MODE
Power - Max 225mW
FET Type N-Channel
Transistor Application AMPLIFIER
Input Capacitance (Ciss) (Max) @ Vds 5pF @ 10V
Drain to Source Voltage (Vdss) 25V
JEDEC-95 Code TO-236AB
DS Breakdown Voltage-Min 25V
FET Technology JUNCTION
Feedback Cap-Max (Crss) 1.5 pF
Current - Drain (Idss) @ Vds (Vgs=0) 4mA @ 10V
Voltage - Cutoff (VGS off) @ Id 5V @ 0.5nA
Compliance
RoHS Status ROHS3 Compliant
