2N5639RLRAG
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Tape & Reel (TR) Through Hole N-Channel SINGLE JFET Transistor 25mA @ 20V 310mW 30V 60Ohm
PDF
/
Inventory: 2864
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Resistance - RDS(On) 60Ohm
Voltage - Breakdown (V(BR)GSS) 35V
Current - Drain (Idss) @ Vds (Vgs=0) 25mA @ 20V
Feedback Cap-Max (Crss) 4 pF
FET Technology JUNCTION
DS Breakdown Voltage-Min 30V
Drain-source On Resistance-Max 60Ohm
Drain to Source Voltage (Vdss) 30V
Input Capacitance (Ciss) (Max) @ Vds 10pF @ 12V VGS
Transistor Application SWITCHING
FET Type N-Channel
Power - Max 310mW
Operating Mode DEPLETION MODE
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code O-PBCY-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Terminal Finish TIN SILVER COPPER
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
