2N5639
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Bulk Through Hole N-Channel SINGLE JFET Transistor 25mA @ 20V 310mW 30V 60Ohm
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2816
≥1 USD $0.2816
Inventory: 21955
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code O-PBCY-W3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Operating Mode ENHANCEMENT MODE
Power - Max 310mW
FET Type N-Channel
Transistor Application SWITCHING
Input Capacitance (Ciss) (Max) @ Vds 10pF @ 12V VGS
Drain to Source Voltage (Vdss) 30V
Drain-source On Resistance-Max 60Ohm
FET Technology METAL-OXIDE SEMICONDUCTOR
Feedback Cap-Max (Crss) 4 pF
Current - Drain (Idss) @ Vds (Vgs=0) 25mA @ 20V
Voltage - Breakdown (V(BR)GSS) 35V
Resistance - RDS(On) 60Ohm
Compliance
RoHS Status ROHS3 Compliant
