2SJ01630RL image
Favorite
2SJ01630RL image
Favorite
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - JFETs
Description JFET P-CH 20MA 150MW MINI-3
PDF
/
Inventory: 7447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package Mini3-G1

Technical

Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2008
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -65V
Max Power Dissipation 150mW
Current Rating -20mA
Base Part Number 2SJ0163
Power - Max 150mW
FET Type P-Channel
Input Capacitance (Ciss) (Max) @ Vds 12pF @ 10V
Drain to Source Voltage (Vdss) 65V
Continuous Drain Current (ID) 20mA
Input Capacitance 12pF
Current - Drain (Idss) @ Vds (Vgs=0) 600μA @ 10V
Voltage - Cutoff (VGS off) @ Id 1.5V @ 10μA
Resistance - RDS(On) 300Ohms
Current Drain (Id) - Max 20mA

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
