RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description JFET N-CH 30V 625MW TO92
PDF
/
Inventory: 4267
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3

Technical

Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 30V
Max Power Dissipation 625mW
Current Rating 50mA
Base Part Number 2N4303
Element Configuration Single
Power Dissipation 625mW
FET Type N-Channel
Drain to Source Voltage (Vdss) 30V
Continuous Drain Current (ID) 10mA
Gate to Source Voltage (Vgs) -30V
Current - Drain (Idss) @ Vds (Vgs=0) 4mA @ 15V
Voltage - Cutoff (VGS off) @ Id 6V @ 1nA

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
