MMBF5457LT1
RoHS
/
Package SOT-23-3
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 25V 0.225W SOT23
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.0836
≥1 USD $0.0836
≥10 USD $0.0684
≥100 USD $0.0665
≥500 USD $0.0646
≥1000 USD $0.06175
≥10000 USD $0.05605
Inventory: 36007
Minimum: 1
-
+
Technical Details
Technical
Drain to Source Voltage (Vdss) 25V
Polarity/Channel Type N-CHANNEL
Continuous Drain Current (ID) 5mA
Gate to Source Voltage (Vgs) 25V
Drain to Source Breakdown Voltage 25V
Input Capacitance 7pF
FET Technology JUNCTION
Transistor Application AMPLIFIER
Power Dissipation 200mW
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 10mA
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 225mW
Voltage - Rated DC 25V
Subcategory Other Transistors
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2005
Packaging Cut Tape (CT)
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 3
Package / Case SOT-23-3
Mount Surface Mount
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
