J113_D26Z
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 35V 625MW TO92
PDF
/
Inventory: 9044
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 200.998119mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 35V
Max Power Dissipation 625mW
Current Rating 50mA
Base Part Number J113
Element Configuration Single
FET Type N-Channel
Drain to Source Voltage (Vdss) 35V
Continuous Drain Current (ID) 2mA
Gate to Source Voltage (Vgs) -35V
Current - Drain (Idss) @ Vds (Vgs=0) 2mA @ 15V
Voltage - Cutoff (VGS off) @ Id 500mV @ 1μA
Resistance - RDS(On) 100Ohm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
