J112RLRA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 35V 0.35W TO92
PDF
/
Inventory: 8826
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Resistance - RDS(On) 50Ohm
Voltage - Cutoff (VGS off) @ Id 1V @ 1μA
Current - Drain (Idss) @ Vds (Vgs=0) 5mA @ 15V
Feedback Cap-Max (Crss) 5 pF
FET Technology JUNCTION
Drain-source On Resistance-Max 50Ohm
Gate to Source Voltage (Vgs) 35V
Drain to Source Voltage (Vdss) 35V
Transistor Application CHOPPER
FET Type N-Channel
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number J112
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 50mA
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Position BOTTOM
Max Power Dissipation 350mW
Voltage - Rated DC 35V
Subcategory Other Transistors
HTS Code 8541.21.00.95
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
