J109
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
FAIRCHILD SEMICONDUCTOR J109JFET Transistor, JFET, -25 V, 40 mA, 6 V, TO-92, JFET
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.31768
≥100 USD $0.22088
≥500 USD $0.17248
≥1000 USD $0.140202
≥3000 USD $0.12533
Inventory: 29186
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.86mm
Length 4.58mm
Height 4.58mm
Technical
Resistance - RDS(On) 12Ohm
Voltage - Cutoff (VGS off) @ Id 2V @ 10nA
Current - Drain (Idss) @ Vds (Vgs=0) 40mA @ 15V
Feedback Cap-Max (Crss) 15 pF
Drain to Source Resistance 12Ohm
FET Technology JUNCTION
Gate to Source Voltage (Vgs) -25V
Continuous Drain Current (ID) 40mA
Drain to Source Voltage (Vdss) 25V
Breakdown Voltage -25V
Transistor Application SWITCHING
FET Type N-Channel
Power Dissipation 625mW
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Base Part Number J109
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 40mA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC 25V
Subcategory Other Transistors
HTS Code 8541.21.00.95
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 201mg
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
