FJX597JHTF
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 20V 0.1W SOT323
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 28011
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Number of Pins 3
Supplier Device Package SC-70 (SOT323)
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 20V
Max Power Dissipation 100mW
Current Rating 1mA
Element Configuration Single
Power - Max 100mW
FET Type N-Channel
Input Capacitance (Ciss) (Max) @ Vds 3.5pF @ 5V
Drain to Source Voltage (Vdss) 20V
Continuous Drain Current (ID) 1mA
Gate to Source Voltage (Vgs) -20V
Input Capacitance 3.5pF
Current - Drain (Idss) @ Vds (Vgs=0) 150μA @ 5V
Voltage - Cutoff (VGS off) @ Id 600mV @ 1μA
Voltage - Breakdown (V(BR)GSS) 20V
Current Drain (Id) - Max 1mA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
