2N5461RLRAG
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET P-CH 40V 0.35W TO92
PDF
/
Inventory: 6761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Voltage - Cutoff (VGS off) @ Id 1V @ 1μA
Current - Drain (Idss) @ Vds (Vgs=0) 2mA @ 15V
Feedback Cap-Max (Crss) 2 pF
FET Technology JUNCTION
Gate to Source Voltage (Vgs) 40V
Drain to Source Voltage (Vdss) 40V
Input Capacitance (Ciss) (Max) @ Vds 7pF @ 15V
Transistor Application AMPLIFIER
FET Type P-Channel
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number 2N5461
Time@Peak Reflow Temperature-Max (s) 40
Current Rating -10mA
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Max Power Dissipation 350mW
Voltage - Rated DC -40V
Subcategory FET General Purpose Small Signal
HTS Code 8541.21.00.95
Additional Feature LOW NOISE
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -65°C~135°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 3 days ago)
