2N5461
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET P-CH 40V 0.35W TO92
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.42194
≥1 USD $0.42194
Inventory: 271
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Supplier Device Package TO-92-3
Weight 201mg
Technical
Operating Temperature -65°C~135°C TJ
Packaging Bulk
Published 2006
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 10V
Max Power Dissipation 350mW
Current Rating 10mA
Base Part Number 2N5461
Element Configuration Single
Power Dissipation 350mW
Power - Max 350mW
FET Type P-Channel
Input Capacitance (Ciss) (Max) @ Vds 7pF @ 15V
Breakdown Voltage 40V
Drain to Source Voltage (Vdss) 40V
Continuous Drain Current (ID) 10mA
Gate to Source Voltage (Vgs) 40V
Input Capacitance 7pF
Current - Drain (Idss) @ Vds (Vgs=0) 2mA @ 15V
Voltage - Cutoff (VGS off) @ Id 1V @ 1μA
Voltage - Breakdown (V(BR)GSS) 40V
Dimensions
Height 5.33mm
Length 5.2mm
Width 4.19mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
