2N5460
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Bulk Through Hole P-Channel Single JFET Transistor 1mA @ 15V 3mA 350mW 40V
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.84388
≥1 USD $0.84388
Inventory: 140
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 4.19mm
Length 5.21mm
Height 5.33mm
Technical
Voltage - Breakdown (V(BR)GSS) 40V
Voltage - Cutoff (VGS off) @ Id 750mV @ 1μA
Current - Drain (Idss) @ Vds (Vgs=0) 1mA @ 15V
Input Capacitance 7pF
Gate to Source Voltage (Vgs) 40V
Continuous Drain Current (ID) 3mA
Drain to Source Voltage (Vdss) 40V
Breakdown Voltage 40V
Input Capacitance (Ciss) (Max) @ Vds 7pF @ 15V
FET Type P-Channel
Power - Max 350mW
Power Dissipation 350mW
Element Configuration Single
Base Part Number 2N5460
Current Rating 10mA
Max Power Dissipation 350mW
Voltage - Rated DC -40V
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2006
Packaging Bulk
Operating Temperature -65°C~135°C TJ
Physical
Weight 201mg
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
