2N5459
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 25V 625MW TO92
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.53675
≥1 USD $0.53675
≥10 USD $0.4408
≥100 USD $0.42655
≥500 USD $0.41325
≥1000 USD $0.399
Inventory: 15071
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Weight 201mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2000
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Voltage - Rated DC 25V
Max Power Dissipation 625mW
Peak Reflow Temperature (Cel) NOT SPECIFIED
Current Rating 10mA
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 2N5459
Element Configuration Single
Power Dissipation 625mW
FET Type N-Channel
Input Capacitance (Ciss) (Max) @ Vds 7pF @ 15V
Breakdown Voltage 25V
Drain to Source Voltage (Vdss) 15V
Continuous Drain Current (ID) 16mA
Gate to Source Voltage (Vgs) -25V
Current - Drain (Idss) @ Vds (Vgs=0) 4mA @ 15V
Voltage - Cutoff (VGS off) @ Id 2V @ 10nA
Dimensions
Height 4.7mm
Length 4.7mm
Width 3.93mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
