STGWT30V60F

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT Transistors 600V 30A Hi Spd TrenchGate FieldStop
PDF
/
Buying Options
Total Price: USD $2.97
Unit Price: USD $2.9744
≥1 USD $2.9744
≥10 USD $2.35371
≥100 USD $2.0174
≥500 USD $1.793246
Inventory: 633
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 32 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3, SC-65-3
Number of Pins 3

Technical

Operating Temperature -55°C~175°C TJ
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Power Dissipation 260W
Base Part Number STGWT30
Element Configuration Single
Power Dissipation 260W
Input Type Standard
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 60A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.3V
Test Condition 400V, 30A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 30A
IGBT Type Trench Field Stop
Gate Charge 163nC
Current - Collector Pulsed (Icm) 120A
Td (on/off) @ 25°C 45ns/189ns
Switching Energy 383μJ (on), 233μJ (off)

Dimensions

Height 20.1mm
Length 15.8mm
Width 5mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
