STGW80V60F
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 120A 3-Pin TO-247 Tube
PDF
/
Buying Options
Total Price: USD $5.84
Unit Price: USD $5.8432
≥1 USD $5.8432
≥10 USD $5.24744
≥100 USD $4.96056
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 1.8mJ (on), 1mJ (off)
Td (on/off) @ 25°C 60ns/220ns
Current - Collector Pulsed (Icm) 240A
Gate Charge 448nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 80A
Test Condition 400V, 80A, 10 Ω, 15V
Collector Emitter Saturation Voltage 1.85V
Collector Emitter Breakdown Voltage 600V
Max Collector Current 120A
Collector Emitter Voltage (VCEO) 600V
Power - Max 469W
Input Type Standard
Element Configuration Single
Base Part Number STGW80
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 469W
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Weight 38.000013g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 20 Weeks
