STGW40H65FB

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT Transistors 650V 40A Trench Gate Field-Stop IGBT
PDF
/
Buying Options
Total Price: USD $3.38
Unit Price: USD $3.3792
≥1 USD $3.3792
≥10 USD $2.67549
≥100 USD $2.29335
≥500 USD $2.038546
≥1000 USD $1.745506
≥3000 USD $1.643585
Inventory: 863
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 5.15mm
Length 15.75mm
Height 20.15mm

Technical

Switching Energy 498mJ (on), 363mJ (off)
Td (on/off) @ 25°C 40ns/142ns
Current - Collector Pulsed (Icm) 160A
Gate Charge 210nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2.3V @ 15V, 40A
Test Condition 400V, 40A, 5 Ω, 15V
Collector Emitter Saturation Voltage 1.6V
Collector Emitter Breakdown Voltage 650V
Max Collector Current 80A
Collector Emitter Voltage (VCEO) 650V
Input Type Standard
Power Dissipation 283W
Element Configuration Single
Base Part Number STGW40
Max Power Dissipation 283W
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -55°C~175°C TJ

Physical

Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 20 Weeks
