STGW30H60DF
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 60A 260W TO247
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1513
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -40°C~175°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Max Power Dissipation 260W
Base Part Number STGW30
Element Configuration Single
Power Dissipation 260W
Input Type Standard
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 60A
Reverse Recovery Time 110 ns
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.4V
Test Condition 400V, 30A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 30A
IGBT Type Trench Field Stop
Gate Charge 105nC
Current - Collector Pulsed (Icm) 120A
Td (on/off) @ 25°C 50ns/160ns
Switching Energy 350μJ (on), 400μJ (off)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
