STGW20V60F
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT Transistors 600V 20A Hi Spd TrenchGate FieldStop
PDF
/
Buying Options
Total Price: USD $3.25
Unit Price: USD $3.2472
≥1 USD $3.2472
≥10 USD $2.57459
≥100 USD $2.20682
≥500 USD $1.961626
≥1000 USD $1.679638
≥3000 USD $1.581554
Inventory: 157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 167W
Base Part Number STGW20
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 167W
Input Type Standard
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 40A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.3V
Turn On Time 49 ns
Test Condition 400V, 20A, 15V
Vce(on) (Max) @ Vge, Ic 2.2V @ 15V, 20A
Turn Off Time-Nom (toff) 173 ns
IGBT Type Trench Field Stop
Gate Charge 116nC
Current - Collector Pulsed (Icm) 80A
Td (on/off) @ 25°C 38ns/149ns
Switching Energy 200μJ (on), 130μJ (off)
Dimensions
Height 20.15mm
Length 15.75mm
Width 5.15mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
