STGP7H60DF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 14A 88W TO-220AB
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.679184
≥100 USD $0.538208
≥500 USD $0.45621
≥1000 USD $0.45122
Inventory: 1266
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Power Dissipation 88W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STGP7
Input Type Standard
Power - Max 88W
Collector Emitter Voltage (VCEO) 1.95V
Max Collector Current 14A
Reverse Recovery Time 136 ns
Collector Emitter Breakdown Voltage 600V
Test Condition 400V, 7A, 47 Ω, 15V
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 7A
IGBT Type Trench Field Stop
Gate Charge 46nC
Current - Collector Pulsed (Icm) 28A
Td (on/off) @ 25°C 30ns/160ns
Switching Energy 99μJ (on), 100μJ (off)
Compliance
RoHS Status ROHS3 Compliant
