STGP5H60DF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
TRENCH GATE FIELD-STOP IGBT, H S
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.74536
≥100 USD $0.590656
≥500 USD $0.500685
≥1000 USD $0.49522
Inventory: 1108
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 56μJ (on), 78.5μJ (off)
Td (on/off) @ 25°C 30ns/140ns
Current - Collector Pulsed (Icm) 20A
Gate Charge 43nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 5A
Test Condition 400V, 5A, 47 Ω, 15V
Collector Emitter Breakdown Voltage 600V
Reverse Recovery Time 134.5 ns
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 1.95V
Power - Max 88W
Input Type Standard
Base Part Number STGP5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 88W
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 20 Weeks
