STGP19NC60KD
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 35A 3-Pin(3+Tab) TO-220 T/R
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.288
≥1 USD $2.288
≥10 USD $1.835152
≥100 USD $1.509904
≥500 USD $1.277637
≥1000 USD $1.084054
≥3000 USD $1.029855
Inventory: 490
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
Gate-Emitter Thr Voltage-Max 6.5V
Gate-Emitter Voltage-Max 20V
Switching Energy 165μJ (on), 255μJ (off)
Td (on/off) @ 25°C 30ns/105ns
Current - Collector Pulsed (Icm) 75A
Gate Charge 55nC
Turn Off Time-Nom (toff) 270 ns
Vce(on) (Max) @ Vge, Ic 2.75V @ 15V, 12A
Test Condition 480V, 12A, 10 Ω, 15V
Turn On Time 38 ns
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-220AB
Reverse Recovery Time 31 ns
Max Collector Current 35A
Collector Emitter Voltage (VCEO) 600V
Turn-Off Delay Time 105 ns
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 125W
Turn On Delay Time 30 ns
Input Type Standard
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number STGP19
Max Power Dissipation 125W
Subcategory Insulated Gate BIP Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series PowerMESH?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 6.000006g
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
