STGFW40H65FB
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 650V 80A 3-Pin TO-3PF Tube
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.948
≥1 USD $2.948
≥10 USD $2.33317
≥100 USD $1.9998
≥500 USD $1.7776
≥1000 USD $1.522074
≥3000 USD $1.433194
Inventory: 677
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 32 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3 Full Pack
Number of Pins 3
Supplier Device Package TO-3PF-3
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Max Power Dissipation 62.5W
Base Part Number STGFW40
Element Configuration Single
Input Type Standard
Power - Max 62.5W
Collector Emitter Voltage (VCEO) 2V
Max Collector Current 80A
Collector Emitter Breakdown Voltage 650V
Voltage - Collector Emitter Breakdown (Max) 650V
Current - Collector (Ic) (Max) 80A
Test Condition 400V, 40A, 5Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 40A
IGBT Type Trench Field Stop
Gate Charge 210nC
Current - Collector Pulsed (Icm) 160A
Td (on/off) @ 25°C 40ns/142ns
Switching Energy 498μJ (on), 363μJ (off)
Compliance
RoHS Status ROHS3 Compliant
