STGFW35HF60W
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT Transistors 35A 600V UltraF IGBT Improved Eoff Temp
PDF
/
Buying Options
Total Price: USD $6.13
Unit Price: USD $6.1336
≥1 USD $6.1336
≥10 USD $4.8972
≥100 USD $4.38181
Inventory: 356
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3 Full Pack
Number of Pins 3
Weight 6.961991g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Subcategory Insulated Gate BIP Transistors
Max Power Dissipation 88W
Base Part Number STGFW35
Element Configuration Single
Input Type Standard
Power - Max 88W
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 36A
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.5V
Test Condition 400V, 20A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 20A
Gate Charge 140nC
Current - Collector Pulsed (Icm) 150A
Td (on/off) @ 25°C 30ns/175ns
Switching Energy 290μJ (on), 185μJ (off)
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 5.75V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
