STGF30NC60S
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 22A 3-Pin(3+Tab) TO-220FP Tube
PDF
/
Buying Options
Total Price: USD $13.8
Unit Price: USD $13.8016
≥1 USD $13.8016
≥10 USD $11.32495
≥100 USD $10.9706
≥500 USD $10.6172
≥1000 USD $10.26285
Inventory: 1674
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Thr Voltage-Max 5.75V
Gate-Emitter Voltage-Max 20V
Switching Energy 300μJ (on), 1.28mJ (off)
Td (on/off) @ 25°C 21.5ns/180ns
Current - Collector Pulsed (Icm) 150A
Gate Charge 96nC
Turn Off Time-Nom (toff) 555 ns
Vce(on) (Max) @ Vge, Ic 1.9V @ 15V, 20A
Test Condition 480V, 20A, 10 Ω, 15V
Turn On Time 30 ns
Collector Emitter Saturation Voltage 1.5V
Collector Emitter Breakdown Voltage 600V
JEDEC-95 Code TO-220AB
Max Collector Current 22A
Collector Emitter Voltage (VCEO) 600V
Turn-Off Delay Time 260 ns
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Turn On Delay Time 21.5 ns
Input Type Standard
Case Connection ISOLATED
Power Dissipation 40W
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number STGF30
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 40W
Subcategory Insulated Gate BIP Transistors
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PowerMESH?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
