STGF20M65DF2
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT TRENCH 650V 40A TO220FP
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.5576
≥1 USD $1.5576
≥10 USD $1.251184
≥100 USD $1.029512
≥500 USD $0.871112
≥1000 USD $0.73913
≥3000 USD $0.70217
Inventory: 782
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Technical
Operating Temperature -55°C~175°C TJ
Series M
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STGF20
Input Type Standard
Power - Max 32.6W
Reverse Recovery Time 166ns
Voltage - Collector Emitter Breakdown (Max) 650V
Current - Collector (Ic) (Max) 40A
Test Condition 400V, 20A, 12 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 20A
IGBT Type Trench Field Stop
Gate Charge 63nC
Current - Collector Pulsed (Icm) 80A
Td (on/off) @ 25°C 26ns/108ns
Switching Energy 140μJ (on), 560μJ (off)
Compliance
RoHS Status ROHS3 Compliant
