STGD7NC60HT4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
N CH IGBT, PowerMESH, 600V, 25A, DPAK - More Details
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $1.88672
≥100 USD $1.501808
≥500 USD $1.270738
≥1000 USD $1.078202
Inventory: 1567
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Weight 3.949996g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series PowerMESH?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Insulated Gate BIP Transistors
Voltage - Rated DC 600V
Max Power Dissipation 70W
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 7A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STGD7
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Element Configuration Single
Power Dissipation 70W
Input Type Standard
Turn On Delay Time 18.5 ns
Transistor Application POWER CONTROL
Rise Time 8.5 ns
Polarity/Channel Type N-CHANNEL
Turn-Off Delay Time 116 ns
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 25A
JEDEC-95 Code TO-252AA
Collector Emitter Breakdown Voltage 600V
Collector Emitter Saturation Voltage 2.5V
Max Breakdown Voltage 600V
Turn On Time 25.5 ns
Test Condition 390V, 7A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 7A
Continuous Collector Current 14A
Turn Off Time-Nom (toff) 221 ns
Gate Charge 35nC
Current - Collector Pulsed (Icm) 50A
Td (on/off) @ 25°C 18.5ns/72ns
Switching Energy 95μJ (on), 115μJ (off)
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 5.75V
Dimensions
Height 2.4mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
