STGD7NB120ST4

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Trans IGBT Chip N-CH 1.2KV 10A 3-Pin(3+Tab) IPAK T/R
PDF
/
Inventory: 9920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount, Through Hole
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3

Technical

Packaging Tape & Reel (TR)
Series PowerMESH?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 55W
Base Part Number STGD7
Element Configuration Single
Input Type Standard
Power - Max 55W
Collector Emitter Voltage (VCEO) 2.1V
Max Collector Current 10A
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Test Condition 960V, 7A, 1k Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 7A
Gate Charge 29nC
Current - Collector Pulsed (Icm) 20A
Td (on/off) @ 25°C 570ns/-
Switching Energy 3.2μJ (on), 15mJ (off)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
