STGBL6NC60DIT4
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 600V 14A 3-Pin(2+Tab) D2PAK T/R
PDF
/
Inventory: 2487
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series PowerMESH?
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Subcategory Insulated Gate BIP Transistors
Max Power Dissipation 56W
Terminal Form GULL WING
Base Part Number STGBL6
Pin Count 4
JESD-30 Code R-PSSO-G2
Number of Elements 1
Element Configuration Single
Input Type Standard
Power - Max 56W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 600V
Max Collector Current 14A
Reverse Recovery Time 23 ns
Collector Emitter Breakdown Voltage 600V
Max Breakdown Voltage 600V
Turn On Time 10.5 ns
Test Condition 390V, 3A, 10 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.9V @ 15V, 3A
Turn Off Time-Nom (toff) 122 ns
Gate Charge 12nC
Current - Collector Pulsed (Icm) 18A
Td (on/off) @ 25°C 6.7ns/46ns
Switching Energy 32μJ (on), 24μJ (off)
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 5.75V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
