STGB3HF60HD
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 600V 7.5A D2PAK
PDF
/
Inventory: 3697
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 8 months ago)
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STGB3
Input Type Standard
Power - Max 38W
Reverse Recovery Time 85ns
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 7.5A
Test Condition 400V, 1.5A, 100 Ω, 15V
Vce(on) (Max) @ Vge, Ic 2.95V @ 15V, 1.5A
Gate Charge 12nC
Current - Collector Pulsed (Icm) 18A
Td (on/off) @ 25°C 11ns/60ns
Switching Energy 19μJ (on), 12μJ (off)
Compliance
RoHS Status ROHS3 Compliant
