STGB15M65DF2
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
TRENCH GATE FIELD-STOP IGBT M SE
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6192
≥1 USD $1.6192
≥10 USD $1.34728
≥100 USD $1.072104
≥500 USD $0.907192
Inventory: 1213
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 90μJ (on), 450μJ (off)
Td (on/off) @ 25°C 24ns/93ns
Current - Collector Pulsed (Icm) 60A
Gate Charge 45nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 15A
Test Condition 400V, 15A, 12 Ω, 15V
Max Breakdown Voltage 650V
Collector Emitter Breakdown Voltage 650V
Reverse Recovery Time 142 ns
Max Collector Current 30A
Collector Emitter Voltage (VCEO) 2V
Power - Max 136W
Input Type Standard
Base Part Number STGB15
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 136W
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 30 Weeks
