STGB10NB37LZ
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Trans IGBT Chip N-CH 440V 20A Automotive 3-Pin(2+Tab) D2PAK Tube
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8987
≥1 USD $0.8987
≥10 USD $0.73815
≥100 USD $0.7144
≥500 USD $0.6916
≥1000 USD $0.6688
Inventory: 1518
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.35mm
Length 10.4mm
Height 4.6mm
Technical
Gate-Emitter Thr Voltage-Max 2.4V
Switching Energy 2.4mJ (on), 5mJ (off)
Td (on/off) @ 25°C 1.3μs/8μs
Current - Collector Pulsed (Icm) 40A
Gate Charge 28nC
Turn Off Time-Nom (toff) 17800 ns
Vce(on) (Max) @ Vge, Ic 1.8V @ 4.5V, 10A
Test Condition 328V, 10A, 1k Ω, 5V
Turn On Time 860 ns
Collector Emitter Saturation Voltage 1.2V
Collector Emitter Breakdown Voltage 440V
Max Collector Current 20A
Collector Emitter Voltage (VCEO) 1.8V
Polarity/Channel Type N-CHANNEL
Transistor Application AUTOMOTIVE IGNITION
Input Type Standard
Case Connection COLLECTOR
Power Dissipation 125W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STGB10
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Max Power Dissipation 125W
Subcategory Insulated Gate BIP Transistors
Additional Feature VOLTAGE CLAMPING
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PowerMESH?
Packaging Tube
Operating Temperature -65°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
