RGTH80TK65GC11
RoHS
RoHS compliant
RoHS compliantPackage TO-3PFM, SC-93-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT
PDF
/
Buying Options
Total Price: USD $2.46
Unit Price: USD $2.464
≥1 USD $2.464
≥10 USD $1.98117
≥100 USD $1.63005
Inventory: 484
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Td (on/off) @ 25°C 34ns/120ns
Current - Collector Pulsed (Icm) 160A
Gate Charge 79nC
IGBT Type Trench Field Stop
Turn Off Time-Nom (toff) 194 ns
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 40A
Test Condition 400V, 40A, 10 Ω, 15V
Turn On Time 84 ns
Current - Collector (Ic) (Max) 31A
Voltage - Collector Emitter Breakdown (Max) 650V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 66W
Input Type Standard
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2016
Operating Temperature -40°C~175°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-3PFM, SC-93-3
Mounting Type Through Hole
Supply Chain
Factory Lead Time 17 Weeks
